Bellow 1340
Large-capacity depositor with ergonomic design.
- 5 mL to 1340 mL deposit range
- 220 L stainless steel hopper
- Industrial-grade design
What It Does
The Bellow 1340 features an exceptionally large 220L hopper—the largest in the Beldos line—for operations where minimizing refill interruptions matters. The ergonomic compact non-adjustable frame positions the hopper low for easy filling and cleaning while maintaining efficient depositing operation.
This design works particularly well for long production runs of single products where hopper capacity directly affects throughput. Less time refilling means more time depositing.
Perfect For:
- Long production runs with single products
- Operations prioritizing minimal refill interruptions
- High-volume single-SKU production
- Facilities with limited operator availability
Technical Specifications:
- Power: Pneumatic (air only, no electricity)
- Air requirements: 219 l/min at 30 deposits/min, 7 Bar / 102 PSI
- Deposit range: 5-1340ml
- Hopper capacity: 220L (largest capacity available)
- Frame: Compact, non-adjustable, ergonomic design
- Construction: Stainless steel
Applications:
Cake batter, muffins, jam, jelly, fruit filling, cream, mousse, meringue, ice cream, yogurt, soup, sauce, mashed potatoes, minced meat, salad
